Useful information

PIRIGRAIN technical department

From the farm to the port silo, there is bound to be a PIRIGRAIN solution to meet your needs for insecticide protection of stored grains – a global solution, tailor-made by our Technical Service which provides all the equipment: the design of the equipment , the study of the installation, the assembly and the technical assistance proper to the maintenance and the regular controls on sites.

Call us to find out more: after visiting one of our specialized advisers, we will establish together an accurate diagnosis of your needs and the corresponding specifications.

Cold Nebulization

To effectively protect the stored grains, the Compagnie Générale des Insecticides developed in 1966 a revolutionary process: « cold fogging ». Regularly improved since then, this process involves coating the grain in motion with an extremely fine mist ensuring a homogeneous distribution of the insecticide.

Surface treatment

Floors, walls and supports nearby: all surfaces that may come into contact with stored grain may be a source of infestation and must be treated with a pre-press or maintained agricultural sprayer. The insecticide thus applied will be active for several months.

Volume treatment

In addition to the surface treatment, it is also possible to proceed with the volume treatment that makes it possible to reach the very high parts. Its effectiveness will be all the greater as the local will have the capacity to hold the insecticide in the atmosphere for a sufficient time to act, the necessary contact time may vary from 1 to 6 hours depending on the thiness of the fog and the temperature. The equipment used must generate a spectrum of very fine dry or liquid particles in order to reach the furthest parts of the generator and keep them suspended in the atmosphere as long as possible.

Which material to choose?

Rather than using a thermal fogger that generates ultra-fine particles (0.3 to 1 micron) but alters the active ingredients by the heat released during the injection on the exhaust of an internal combustion engine, SOJAM recommends the use of a cold atomizer, electric or thermal motor. In this case, the active ingredients are preserved even if the particles are larger (between 9 and 30 microns). And the turbocharger units can reach much higher heights (up to 30 m), which is an additional guarantee of efficiency.

Gamme ECHO

3 appareils en coffret avec porte vitrée, pompe doseuse à membrane et afficheur de débit. Faible encombrement, simplicité d’utilisation, moteur pas à pas, doseur PVDF. Norme ATEX.

Gamme MAJOR G

4 appareils équipés en série d’une pompe G avec corps inox, automatisme, afficheur de débit, totaliseur et Altivar. Norme ATEX.

2) Les atomiseurs à froid pour le traitement des locaux

Gamme ATOMIST

Mobiles, facilement maniables et très simples d’utilisation, les appareils de la gamme ATOMIST de PIRIGRAIN sont des atomiseurs à froid actionnés par un moteur-ventilateur électrique à haute vitesse et à 2 étages. Idéal pour la désinsectisation des locaux de stockage. La haute vitesse de l’air pulsé par ces appareils leur permettent une portée exceptionnelle, en un brouillard extrêmement fin et compact de particules de même taille.

Pulvérisateur autonome basse tension mobile avec lance télescopique 3 mètres

• Autonome, batterie longue durée : 5 h de pulvérisation continue (200 à 240 L)
• Mobile, Panneau de commande indiquant le niveau de charge de la batterie + alerte sonore
• Module électronique à microprocesseur contrôlant la charge de la batterie et le moteur de la pompe
